• Model NO.：1A1, 1B1, 1A21, 1V1,3A1, 3V1, 3B1, 4A9, 4A1P, 11V9
• Circular Degree：<1
• Technics：Electroplating
• Working Style：Tool Grinding
• Diamond & CBN Wheels for Saw Blades：Diamond & CBN Wheels for Knife Grinding
• Diamond & CBN Wheels for Milling Cutter：Diamond & CBN Wheels for Round Tools
• Conventional, CBN or Diamond Wheels：Disc Grinding Operations on Double Disc Grinders
• Flute Grinding and Thread Grinding：Surface and Creepfeed Grinding
• Precision Grinding：Centreless Grinding
• Gear Grinding Operations：Regrinding and Reshaping Rolls
• Transport Package：By Carton
• Specification：EN 12413
• Trademark：BONDFLEX, SAILI, SUMENG
• Origin：Jiangsu China
• HS Code：68042210
• Production Capacity：25000 pieces each day

Basic Info.

Model NO. 1A1, 1B1, 1A21, 1V1,3A1, 3V1, 3B1, 4A9, 4A1P, 11V9 Circular Degree <1 Technics Electroplating Working Style Tool Grinding Diamond & CBN Wheels for Saw Blades Diamond & CBN Wheels for Knife Grinding Diamond & CBN Wheels for Milling Cutter Diamond & CBN Wheels for Round Tools Conventional, CBN or Diamond Wheels Disc Grinding Operations on Double Disc Grinders Flute Grinding and Thread Grinding Surface and Creepfeed Grinding Precision Grinding Centreless Grinding Gear Grinding Operations Regrinding and Reshaping Rolls Transport Package By Carton Specification EN 12413 Trademark BONDFLEX, SAILI, SUMENG Origin Jiangsu China HS Code 68042210 Production Capacity 25000 pieces each day

Product Description

Specialized in manufacturing abrasive products, including bonded abrasives and super abrasives, brown aluminum oxide, reinforced cutting wheels and grinding wheels, diamond & CBN grinding wheels, etc.

Resin bonded wheels

- Carbide insert grinding wheels
- Cylindrical grinding wheels
- Creep feed wheels
- Tip saw grinding wheels
- Carbide/steel alloy grinding wheels
- Diamond flaring cup wheels
- Centerless grinding wheels
- Other be available upon requests

Face Grind Akemat & UT. MA
FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4A2 150mm x 3/8 x 32mm D 240 R 125 B 1/16 W=1/8
B12V9 200mm x 1/2 x 32mm CBN 220 R 100 B 1/16 S=20°

FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4V2 6 x 13/32 x 32mm D 320 R 100 B 3/32 W=1/8
B4V2 200mm x 13mm x 32mm CBN 180 R 100 B 2mm W=4mm

Top Grind Akemat & UT. MA
TOP GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D14B1 125mm x 8mm x 32mm D 180/400 R 100 B 1/4 U=5mm
D3M1 125mm x 8mm x 32mm D 220/600 R 125/100 B 3/8 U=4mm


Side Grind Akemat & UT. MA
SIDE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT
D4A1 3 x 9/16 x 20mm D 220 R 75 B 3/16 U=5/32
B4A1 100mm x 9/16 x 20mm CBN 120 R 50 B 5/32 U=5/32

Face Grind Vollmer

FACE GRINDING WHEELS FOR VOLLMER EQUIPMENT
D4A2 115mm x 11mm x 32mm D 280 R 100 B 1/8 W=1/8
B4A2 125mm x 3/8 x 32mm CBN 180 R 75 B 1/16 W=1/8

D4V2 125mm x 11mm x 32mm D 280 R 100 B 2mm W=4mm
B4V2 125mm x 13mm x 32mm CBN 180 R 75 B 2mm W=4mm
D12V9 125mm x 12mm x 32mm D 240 R 100 B 1/16 S=20°
B12V9 120mm x 12mm x 32mm CBN 180 R 100 B 1/4 S=30°


Top Grind Vollmer

TOP GRINDING WHEELS FOR VOLLMER EQUIPMENT
D6A2 125mm x 18mm x 32mm D 180 R 100 B 1/4 W=3/16
B6A9 115mm x 18mm x 32mm CBN 150 R 75 B 1/8 U=1/4

D6A2 125mm x 21mm x 32mm D 180/400 R 100/75 B 3/8 W=5mm
B6A2 115mm x 18mm x 32mm CBN 120/220 R 100 B 1/4 W=5mm
