• Working Style：High-speed universal
• Disc Diameter：400mm
• Variable Speed：Without Variable Speed
• Grinding range：3-13mm
• Point angle：0-5 degree
• Motor：300W
• gross weight：15kgs
• grinding wheel：CBN or SDC
• Transport Package：Plywood Case
• Specification：15kgs
• Trademark：HOTON
• Origin：China
• HS Code：8460390000
• Production Capacity：20 PCS,Month

Basic Info.

Working Style High-speed universal Disc Diameter 400mm Variable Speed Without Variable Speed Grinding range 3-13mm Point angle 0-5 degree Motor 300W gross weight 15kgs grinding wheel CBN or SDC Transport Package Plywood Case Specification 15kgs Trademark HOTON Origin China HS Code 8460390000 Production Capacity 20 PCS/Month

Product Description

COMPLEX GRINDER MACHINE FEATURES:
1.Complex grinder machine of 3~13 end mill surface and 2~13 twist drill bits;
2.One CBN grinding wheel of 3~13 2flutes,3flutes,4flutes and 6flutes end mills :
3.One CBN grinding wheel also for 2~13 twist drill bits ,no need to change wheel;
4.The cutter angle can be changed and easy to grind.
SPECIFICATIONS:

MODEL	GD-313A
Grinding range	Twist drill bit ,end mills
Material	HSS tungsten
End mill	2,3,4,6 flutes
Capacity	Drill bit:2~13,End mill:3~13
Grinding angle	Drill bit:90°~ 145°,end mill:0°~ 5°
Apex angle	0°
First relief angle	8°
Second relief angle	35°
Power	300W
Voltage	220V  50/60HZ
Wheel speed	5000R.P.M
Machine size	34x19x23cm
Weight	15Kg



Contact Us:

Miss Wynn Sales Manager TENGZHOU HOTON MACHINERY CO.,LTD   MP:0086 16678336698 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
