• Model NO.：alumina
• Customized：Non-Customized
• Model Number：Customer′s Requirements
• Product Name：Alumina Ceramic Microball
• Shape：Round
• Moh′s Hardness：9
• Certificate：ISO9001:2015
• Sample：Free
• Transport Package：PP Woven Bag or Ton Bags with Pallet
• Specification：1-30mm
• Trademark：qimingxing
• Origin：Shandong
• HS Code：6909120000
• Production Capacity：20000

Basic Info.

Model NO. alumina Customized Non-Customized Model Number Customer′s Requirements Product Name Alumina Ceramic Microball Shape Round Moh′s Hardness 9 Certificate ISO9001:2015 Sample Free Transport Package PP Woven Bag or Ton Bags with Pallet Specification 1-30mm Trademark qimingxing Origin Shandong HS Code 6909120000 Production Capacity 20000

Product Description

              92% high al2o3 grinding ceramic ball for industrial materials grinding

Weldable alumina ceramic tiles for coal and other material handling and processing industries. Ceramic linings provide long-lasting solutions to the problems caused by abrasive wear and corrosion in a variety of hostile environments. Alumina ceramic linings will outlast lower grade materials commonly used to line or protect processing and material handling equipment, including Basalt, stainless steel, carbon steel and wear resistant plates, by factors of 3 to 15 times.
QMX's wear resistant ceramic tiles can be cut into any shape and are easy to install and maintain. They are suitable for both wet and dry processing applications. Advanced ceramics combine high strength and toughness with extreme hardness to deliver exceptional wear resistance.

The ceramic pipe tiles,also cale taper tile or Trapezoidal tile, are used on a range of equipment including pipes, tanks, chutes, pumps, flotation cells, thickeners, launders and feed spouts or chutes.

 Physical data:

Category HC90 HC92 HC95 HCT95 HC99 HC-ZTA ZrO2 Al2O3 ≥90% ≥92% ≥95% ≥ 95% ≥ 99% ≥75% / ZrO2 / / / / / ≥21% ≥95% Density >3.50g/ cm3 >3.60g/cm3 >3.65g/cm3 >3.70g/cm3 >3.83g/cm3 >4.10g/cm3 >5.90g/cm3 HV 20 ≥900 ≥950 ≥1000 ≥1100 ≥1200 ≥1350 ≥1100 Rock Hardness HRA ≥80 ≥82 ≥85 ≥88 ≥90 ≥90 ≥88 Bending Strength MPa ≥180 ≥220 ≥250 ≥300 ≥330 ≥400 ≥800 Compression strength MPa ≥970 ≥1050 ≥1300 ≥1600 ≥1800 ≥2000 / Fracture Toughness KIc MPam 1/2 ≥3.5 ≥3.7 ≥3.8 ≥4.0 ≥4.2 ≥4.5 ≥7.0 Wear Volume ≤0.28 cm3 ≤0.25cm3 ≤0.20cm3 ≤0.15cm3 ≤0.10 cm3 ≤0.05cm3 ≤0.02cm3

Packing photos:
