• Model NO.：1A1, 11V9, 12V9, 1V1, 1A1R, 6A2, 14A1, 14F1
• Circular Degree：<0.1
• Technics：Sinter
• Working Style：Tool Grinding
• CBN & Diamond Grinding Wheel：Machines: Walter, Anca, Ewag, Schutte, Schneeberge
• Cutting Tool Manufacturing Industry：Hybrid Bond,Resin Bond Superabrasive
• Grinding HSS, Tool Steel Grinding：Profile Grinding, Grooving and Slot Grinding
• Insert Grinding, Thread Grinding：Surface Grinding, Centerless Grinding, Flute Grind
• Ceramic Grinding, PCB, PCBN：Glass Cutting, Composite Cutting, Tool Grinding
• Small and Micro Tools：Flute, Clearance and Face Surface Grinding
• Shape 1A1r Shape 1A1rh：Cut-off Grinding of Tungsten Carbide Blanks
• Transport Package：by Carton
• Specification：EN 12413
• Trademark：BONDFLEX, SAILI
• Origin：Jiangsu China
• HS Code：68042210
• Production Capacity：25000 Pieces Each Day

Basic Info.

Model NO. 1A1, 11V9, 12V9, 1V1, 1A1R, 6A2, 14A1, 14F1 Circular Degree <0.1 Technics Sinter Working Style Tool Grinding CBN & Diamond Grinding Wheel Machines: Walter, Anca, Ewag, Schutte, Schneeberge Cutting Tool Manufacturing Industry Hybrid Bond,Resin Bond Superabrasive Grinding HSS, Tool Steel Grinding Profile Grinding, Grooving and Slot Grinding Insert Grinding, Thread Grinding Surface Grinding, Centerless Grinding, Flute Grind Ceramic Grinding, PCB, PCBN Glass Cutting, Composite Cutting, Tool Grinding Small and Micro Tools Flute, Clearance and Face Surface Grinding Shape 1A1r Shape 1A1rh Cut-off Grinding of Tungsten Carbide Blanks Transport Package by Carton Specification EN 12413 Trademark BONDFLEX, SAILI Origin Jiangsu China HS Code 68042210 Production Capacity 25000 Pieces Each Day

Product Description

Diamond and CBN Wheels 1A1  1V1   11V9  12V9  1A1R for the Fluting, Gashing and Clearance Angles of Tungsten carbide milling cutters, Tungsten carbide drill bits, Hss milling cutters


They are with the newest  technology, used on CNC Grinder for the Fluting, Gashing and Clearance Angles of the Tungsten Carbide, HSS, Stainless drill, mill and rimer.
Machines: Walter, Anca, Ewag, Schutte, Schneeberger, Makino, TG-5, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner
Availability:
·         Polyimide Bond: for small stock removal. Provides perfect finishing when sharpening carbide tools.
·         Hybrid Bond: for large stock removal and high feed speed, low machine power.

Fluting Wheels
D1A1R 5 x 1/2 x 1-1/4 D 280 R 125 B 3/8

B1A1R 4 x 3/8 x 38mm CBN 220 R 100 B 1/4

D1FF1R 5 x 3/16 x 1-1/4 D 240 R 125 B 1/4

B1FF1R 6 x 3/16 x 2 CBN 180 R 100 B 1/4

D1V1R 5 x 1/2 x 1-1/4 D 280 R 125 B 1/4 30°

B1V1R 4 x 3/8 x 2 CBN 220 R 100 B 1/4 45°


D1V1SP 5 x 1/2 x 1-1/4 D 220 R 125 B 1/4 30°

B1V1SP 4 x 3/8 x 2 CBN 180 R 100 B 1/4 45°

Gashing Wheels
FLUTE GRINDING DIAMOND & GASHING WHEELS

D1V1R 5 x 1/2 x 1-1/4 D 280 R 125 B 1/4 30°

B1V1R 4 x 3/8 x 2 CBN 220 R 100 B 1/4 45°

BALL NOSE FLUTE GRINDING & GASHING WHEELS

D1V1SP 5 x 1/2 x 1-1/4 D 220 R 125 B 1/4 30°

B1V1SP 4 x 3/8 x 2 CBN 180 R 100 B 1/4 45°

Drill Pointing Wheels
BALL NOSE FLUTE GRINDING & GASHING WHEELS

D1V1SP 5 x 1/2 x 1-1/4 D 220 R 125 B 1/4 30°

B1V1SP 4 x 3/8 x 2 CBN 180 R 100 B 1/4 45°

DRILL POINTING AND STEP TOOL WHEELS
D11V2 5 x 1-1/4 x 1-1/4 D 280 R 100 B 1/4 W=1/2

B11C9 5 x 3/4 x 1-1/4 CBN 220 R 100 B 1/8 W=1/2

O. D. Clearance
D11V2 4 x 1-1/4 x 1-1/4 D 320 R 100 B 1/4 W=1/4 5°

B11V5 4 x 1-1/2 x 1-1/4 CBN 220 R 100 B 1/4 W=1/4 10°

D11V5 4 x 1-1/2 x 1-1/4 D 320 R 100 B 1/4 W=1/4 30°

B11V5 4 x 1-1/2 x 1-1/4 CBN 220 R 100 B 1/4 W=1/4 30°

CUTTER DIAMOND GRINDING WHEELS

D11V9 4 x 1-1/2 x 1-1/4 D 280 R 100 B 1/8

B11V9 5 x 1-3/4 x 2 CBN 180 R 100 B 1/8

D11V9 4 x 1-1/2 x 1-1/4 D 280 R 100 B 1/8 - REINFORCED CORE

B11V9 5 x 1-3/4 x 2 CBN 180 R 100 B 1/8 - REINFORCED CORE

D12V9 4 x 7/8 x 20mm D 320 R 125 B 1/16 U=3/8 45°

B12V9 6 x 3/4 x 2 CBN 240 R 100 B 1/8 U=3/8 30°
