Dye Basket Mill
Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.- Type：Basket Bead Grinder Mill
- Power Source：Hydraulic
- Object：Paint Basket Mill
- Application：Chemical
- Disc(Wheel) Type：Basket Bead Mill
- Material：Metal
Base Info
- Model NO.：EBM
- Working Style：High-speed universal
- Disc Diameter：230mm
- Variable Speed：With Variable Speed
- Usage：Industrial Paint Basket Mill
- Product Type：Car Paint Grinding Basket Bead Mill
- Transport Package：Wooden Case
- Specification：CE, SGS
- Trademark：ELE
- Origin：Shanghai, China
- HS Code：8479820090
- Production Capacity：500PCS Per Year, Basket Mill
Description
Model
Basket volume(L)
Main power
Speed(rpm)
Capacity(L)
Media(mm)
Lifting Height(mm)
EBM-4
3.6
4
0-3000
<120
1.8-2.4
800
EBM-7.5
4.9
7.5
0-1500
<200
1.8-2.4
900
EBM-11
6.6
11
0-1500
<260
1.8-2.4
900
EBM-15
9.1
155
0-1500
<350
1.8-2.4
900
EBM-18.5
17.2
18.5
0-1500
<500
1.8-2.4
1100
EBM-22
20.1
22
0-1500
<800
1.8-2.4
1100
EBM-30
32.3
30
0-1500
<1200
1.8-2.4
1100
EBM-37
39.2
37
0-1500
<1500
1.8-2.4
1600
EBM-45
52.3
45
0-1500
<2000
1.8-2.4
1600
EBM-75
85.4
75
0-1500
<3000
1.8-2.4
1800
Characteristic:
1. Integrate dispering and grinding in one machine.Two working procedures realize by one machine and one tank
2. Excellent milling fineness ,high efficiency
3. Easy to clean and easy to change color or other products
4. Frequency Inverter, various speed control
5. Hydraulic Lifting, built-in structure cylinder
6. The machine with cover to avoid material splashing
7. Explosion-proof type for oil/solvent based
