M Shape Diamond Segments for Granite Cutting
Quanzhou JDK Diamond Tools Co., Ltd.- Abrasive：Diamond
- Shape：Fan
- Type：Power Tool Parts, Diamond Segment
- Bonding Agent：Metal
- Size：900--3500mm
- Usage：Stone Cutting
Base Info
- Model NO.：JDK-Segment
- Manufacturing Arts：Sinter
- Kind：Stone Sawing Machine
- ODM/OEM：Yes
- Segment Tye：Sandwich
- Blade Material：Diamond
- Transport Package：White Box,Carton,Plywood Case
- Specification：SGS, CE
- Trademark：JDK
- Origin：Quanzhou, China
- HS Code：82079010
- Production Capacity：10000PCS,Day
Description
JDK M shape Diamond segment for Granite cutting Product Description
| "<<" "K" "M" Shape Segment (Product Code : JDK- << / JDK-K / JDK-M ) | |||||
| Features: | |||||
| 1.The unique "<<" "K" "M" design of segment makes fast diamond exposed and high cutting efficiency | |||||
| 2.The design of segment allows ideal debris removal and bettering cooling. | |||||
| 3.It works in low nosie,small cutter slot which ensure maxium use of stone and uniform thickness | |||||
| Product Name | Specification | Core Thickness | Segment Dimension | Segment Number | Application |
| JDK Block Cutting Segment | Φ900 | 5.0 | 24x7.0/6.2x 15(20) | 64 | Granite |
| Φ1000 | 5.0 | 24x7.0/6.2x 15(20) | 70 | ||
| Φ1200 | 5.5 | 24x7.4/6.6x 15(20) | 80 | ||
| Φ1400 | 6.0 | 24x8.0/7.2x 15(20) | 92 | ||
| Φ1400 | 6.5 | 24x8.4/7.6x 15(20) | 92 | ||
| Φ1600 | 7.2 | 24x9.2/8.4x 15(20) | 104/108 | ||
| Φ1800 | 7.5 | 24x10.0/9.2x 15(20) | 120 | ||
| Φ2000 | 8.0 | 24x10.6/9.8x 15(20) | 128/132 | ||
| Φ2200 | 9.0 | 24x11.0/10.2x15(20) | 132/136 | ||
| Φ2500 | 9.0 | 24x11.5/10.5x15(20) | 140 | ||
| Φ2700 | 9.0 | 24x12.5/11.5x15(20) | 140 | ||
| Φ3000 | 9.3 | 24x13/12x 20 | 160 | ||
| Φ3500 | 9.5 | 24x13.5/13.0/12.2x30 | 180 | ||
Other specification should be made by your request
Customized size is welcome.
