• Model NO.：chemshun ceramic ball
• Customized：Customized
• Item：Ceramic Grinding Balls
• Materials：Alumina
• Alumina Content：68%, 90%, 92%, 95%
• Type：High-Alumina
• Feature：High Hardness, High Density and Anticorrosion
• Field：Ceramic,Metallurgy, Glass, Porcelain, Enamel
• Application：Ball Mill, Pot Mill, Librating Mill
• OEM：Accept
• Water Absorption：<0.01%
• Transport Package：By bags, then fasten on pallet.
• Specification：D3-80mm
• Trademark：Pingxiang chemshun ceramics
• Origin：P. R. CHINA
• HS Code：69091200
• Production Capacity：20000ton,year

Basic Info.

Model NO. chemshun ceramic ball Customized Customized Item Ceramic Grinding Balls Materials Alumina Alumina Content 68%, 90%, 92%, 95% Type High-Alumina Feature High Hardness, High Density and Anticorrosion Field Ceramic,Metallurgy, Glass, Porcelain, Enamel Application Ball Mill, Pot Mill, Librating Mill OEM Accept Water Absorption <0.01% Transport Package By bags, then fasten on pallet. Specification D3-80mm Trademark Pingxiang chemshun ceramics Origin P. R. CHINA HS Code 69091200 Production Capacity 20000ton/year

Product Description

92% Abrasive Ceramic Ball - Alumina Grinding Media Series

This product are featured by high density and hardness, low wear lost, corrosion-resistance etc. They are the perfect high-efficient grinding media for milling glaze/frit, pigment, ceramic materials, and various mine ore powder, they are using ceramics, cements, paints, refractories, inorganic mineral powders etc...

Applied for dry grinding , wet grinding ,mineral grinding ,  quartz grinding ,  lineston grinding ,  iron ore grinding , cement grinding , ceramics plants grinding , pigment grinding , mineral ore grinding , breaking platns .

Applied for ball mill,grinding machine , pot mill , librating mill , pebble mill , Attrition Mill,rod mill , grinding mill , grinding machine , ball grinding mill.

Size and Technical date:

Size:1mm, 3mm, 6mm, 9mm, 13mm, 16mm, 20mm, 25mm, 30mm , 40mm, 50mm, 60mm, 70mm
1/8", 1/4", 1/2", 5/8", 3/4", 1", 1.5", 2", 3"

1: 92%  Alumina content series

A) Al2O3 ≥ 92%
B) Water absorption <0.01%
C) Bulk density ≥ 3.63 g/cm3
D) Mosh hardness: 9
E) Color: White

92% Alumina grinding ball chemical and physical introduction :

Items	Proportion	Items	Proportion
Al2O3	92%	SiO2	<6.5%
others	~2%



Items	Proportion	Items	Proportion
Hardness: Mohr's	9	self Abrasion Loss (24hour)	<0.01%
Density(g/cm3)	3.6g/cm3	Water Absorption	<0.01%
Color	White	Ball method	By cool isostatic-pressing Or by rolling

2: 95% High-alumina grinding ball

A) Al2O3 ≥ 95%  Sio2<3.8%, others:~3%
B) Water absorption <0.01%
C) Bulk density ≥ 3.7 g/cm3
D) Mosh hardness: 9
E) Color: White
F) self abrasion loss : <0.008%

95% Alumina ball chemical and physical introduction :


Items	Proportion	Items	Proportion
Al2O3	95%	SiO2	<3%
others	~2%



Items	Proportion	Items	Proportion
Hardness: Mohr's	9	self Abrasion Loss (24hour)	<0.01%
Density(g/cm3)	3.74g/cm3	Water Absorption	<0.01%
Color	White	Ball method	By cool isostatic-pressing Or by rolling

3: 68% Medium alumina grinding ball series :

A) Al2O3 : 65%~75%
B) Bulk density ≥ 2.93g/cm3
C) Mosh hardness: 8 grade
D) self abrasion loss :0.01
E) Color : white or brown

68% Alumina ball chemical and physical introduction :


Items	Proportion	Items	Proportion
Al2O3	68.62%	SiO2	21.2%
others	~10.18%



Items	Proportion	Items	Proportion
Hardness: Mohr's	7-8	self Abrasion Loss (24hour)	<0.03%
Density(g/cm3)	3.g/cm3	Water Absorption	<0.1%
Color	creamy white	Ball method	By cool isostatic-pressing Or by rolling

More Abrasion ceramics products : abrasion ceramics , Alumina ceramics , wear
resistant ceramics , alumina pipe liner , ceramic tube , alumina cylinder pipe , wear resistant alumina
plate , abrasion ceramic tile , abrasive alumina sheet , friction plain tile , abrasion weldable tile ,
rubber backed ceramic liner , ceramic composite linings , alumina mosaic sheet , ceramic taper
tile for pipe sleeve ,  ceramic ladder tile for pipe steel , engineering  ceramics equipment , pre-fabricated pipe sleeve ,wear resistant bending pipe , abrasion materials
