Laboratory Comprehensive Grinding Planetary Ball Mill
Xiamen Tmax Battery Equipments Limited- Transport Package：Wood Packing
- Trademark：TMAX
- Origin：China
Base Info
- Model NO.：TMAX-OPBM
Description
Stepless speed regulation of frequency converterModel Volume
(L) Applicable jar volume Power(kW) Runing time(min) Revolution
speed(rpm) Rotation speed(rpm) Weight(kg) OPBM-0.4 0.4 50-100ml 0.25 1-9999 47-465 94-930 140 OPBM-1 1 50-250ml 0.75 1-9999 35-370 70-740 280 OPBM-2 2 50-500ml 0.75 1-9999 35-370 70-740 280 OPBM-4 4 250-1000ml 0.75 1-9999 35-370 70-740 285 OPBM-6 6 1-1.5L 0.75 1-9999 35-370 70-740 290 OPBM-8 8 1-2L 1.5 1-9999 35-320 70-640 345 OPBM-10 10 1-2.5L 1.5 1-9999 35-320 70-640 345 OPBM-12 12 1-3L 1.5 1-9999 35-320 70-640 350 OPBM-16 16 2-4L 3 1-9999 30-255 60-510 400 OPBM-20 20 2-5L 4 1-9999 25-215 50-430 710 OPBM-40 40 5-10L 5.5 1-9999 20-195 40-390 1000
Reference table for selection of planetary ball mill style and special function configuration
1. We supply machines with battery technology support.
2. We supply full set of lithium battery equipment for lab research, pilot scale research and production line.
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damage part for you for free.
(L)
speed(rpm)
Model selection guidance
Selection of size of planetary ball mill:According to the number of materials to be ground, choose the size of the planetary mill.Calculation formula for size selection of planetary ball mill: a = C /ρ* 3.Note: A is the size of planetary mill (unit: l), C is the mass of primary grinding material (unit: kg), ρis the bulk density of grinding material (unit: kg /L).For example, if 2kg of material is ground at one time and the bulk density of material is 1.5kg/L, the size of planetary mill in row a = 2/ 1.5*3 = 4L is selected. Planetary ball mill style and special function configuration options:Planetary ball mill is divided into vertical, horizontal, comprehensive, double planet four styles, according to the material grinding requirements, choose the corresponding styles, each style of products can be equipped with air cooling or heating equipment according to the grinding material temperature requirements.
Reference table for selection of planetary ball mill style and special function configuration| Model selection of planetary ball mill | Nature of abrasive material |
| Vertical planetary mill | Grinding of general materials, no special requirements |
| Comprehensive planetary mill or horizontal planetary mill | The material is easy to sink and bind |
| Double planetary mill | Ultra high speed and ultra-fine grinding are required |
| With air cooling device or liquid nitrogen device | The grinding process is hot and needs to be cooled |
| Equipped with vacuum ball milling tank | Easy to oxidize, requiring vacuum environment or atmosphere protection |
| With heating device | High temperature grinding required |
