Glass Straight Edging Machine /Glass Grinding Machine/Glass Bevels/Glass Machine
Qingdao Toyo Industry Co., Ltd.- Type：Angle Grinder
- Power Source：Electricity
- Object：Milling Cutter
- Application：Glass Beveling Machine
- Disc(Wheel) Type：Grinding Disc
- Material：Metal and Steel
Base Info
- Model NO.：TR--MBJ
- Working Style：High-speed universal
- Disc Diameter：Customized
- Variable Speed：Without Variable Speed
- Power：13kw
- Minimum Size of Glass：25*25mm
- Maximum Bevel Surface Width：28 mm
- Processing Angle：5-35 Degrees
- Weight：2000kgs
- Processing Glass Thickness：3-25mm
- Speed：0-4m,Min
- Measurement：3400*1000*1730mm
- Transport Package：Container
- Specification：3400*1000*1730mm
- Trademark：Toyo
- Origin：China
- HS Code：8464201000
- Production Capacity：10000pieces,Year
Description
Horizontal Beveling Machine
Technical Parameters
TYJT-G7
TYJT-G8
Dimensions
3400*1000*1730mm
3400*1000*1730mm
Net Weight
2000kg
2100kg
Glass Processing Thickness
3-8mm
3-8mm
Angle
5-35-degree
5-35-degree
Max Bevel Surface Width
20mm
25mm
Mini Glass Size
40*40mm
40*40mm
Max Glass Size
1600*1600
1600*1600
Max Glass Size with Extension Tables
2440*3000
2440*3000
Speed
0-4m/min
0-4m/min
Voltage
380V, 50HZ, 3 Phrase
220V, 60HZ, 3 Phrase
380V, 50HZ, 3 Phrase
220V, 60HZ, 3 Phrase
Power
13kw
13kw
Number of the Motor Head
7
8
The layout of the wheels
| Position 1 | Position 2 | Position 3 | Position 4 | Position 5 | Position 6 | Position 7 |
| Diamond Wheel | Diamond Wheel | Resin Wheel | Resin Wheel | Resin Wheel | Buffing Wheel | Buffing Wheel |
Product Description
The horizontal beveling machine is a new type of glass deep processing equipment. It changes the traditional glass chain conveying method and adopts the method of synchronous belt conveying, which greatly improves the precision of edging. This machine has an impact structure, a reasonable layout, and a harmonious appearance. It is mainly composed of five major systems, which are the control system, grinding system, clamping and conveying system, cooling system, and receiving system.
Control system: The meter is used to display the current and voltage, and the operation of the machine is clear at a glance.
Grinding system: High-speed three-phase AC motor is selected, and the design service life is up to 20 years.
Clamping transmission system: Select single worm gear speed change, AC frequency conversion speed control, during the running process, the glass running speed can be smoothly transitioned between 0-4 meters to meet different process requirements. The timing belt is made of imported Italian materials, and the surface is adhered with PU and red glue, which reduces the damage rate of the glass during the clamping and transmission process, and ensures sufficient clamping force between the glass and the timing belt during operation, and the glass and the timing belt do not occur. Relative sliding to ensure the accuracy of the grinding line.
Cooling system: It adopts circulating water, double pump, and double tank cooling, and polishing powder are added into one of the water tanks, which not only ensures the circulating cooling but also improves the polishing brightness.
Supporting system: The synchronous belt with the conveying system is used to avoid surface scratches during the operation of the glass. The control part and the working part organically cooperate to display the humanized design.
The whole machine is simple and clear to use, and its grinding accuracy is stable and continuous. It is an ideal equipment for glass deep-processing. It is widely used in home improvement glass, architectural glass, frameless glass and granite, stone plate, ceramic which thickness is within 20mm.
