Ele Ebw Paint Sand Mill

Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.
  • Type：Mill
  • Power Source：Electricity
  • Object：Bead
  • Application：Chemical
  • Disc(Wheel) Type：Grinding Disc
  • Material：Harden Steel or Pure Zirconia

Base Info

  • Model NO.：EBW-30
  • Application Industry：Offset Printing Ink, Inks, Paints, Dope
  • Grinding Medium：Pure Zirconia Ball
  • Usage：Industrial
  • Product Type：Cosmetic
  • Bearing：NSK
  • Motor：Siemens
  • Feeding Pump：Diaphragm Pump Ingersoll Rand
  • Shaft Sealing：German Burgmann Mechanical Seal, Bear Pressure Hig
  • O-Ring：DuPont
  • Transport Package：Wooden Case
  • Specification：EBW-5------EBW-100
  • Trademark：ELE
  • Origin：Shanghai, China
  • HS Code：879820090
  • Production Capacity：200-2000L

Description


Model
Cavity
Volumn(L)
Power
(KW)
Rotation speed
(rmp)
Capacity
(L/H)

Dimension
(mm)

Weight
(kg)
EBW-5
5
5.5
2500
200
1300*1050*450
640
EBW-15
15
18.5
1500
500
1600*1450*650
1100
EBW-20
20
22
1230
800
1600*1450*650
1250
EBW-30
30
30
1060
1200
1650*1550*750
1600
EBW-50
50
45
820
2000
1900*1750*850
2100
EBW-100
100
75
660
3000
2300*1950*950
3600
Note:We can do special design according to customers'need.
