• Model NO.：ceramic mosaic tiles
• Vickers Hardness (Hv5)：1000
• Fracture Toughness：3-4 MPa.M1,2
• Water Absorption：<0.01%
• Maximum Operation Temperature：1450 ºC
• Transport Package：Boxes+Pallets
• Specification：10x10x2mm
• Trademark：Chemshun
• Origin：China
• HS Code：69091200
• Production Capacity：5000 Tons,Year

Basic Info.

Model NO. ceramic mosaic tiles Vickers Hardness (Hv5) 1000 Fracture Toughness 3-4 MPa.M1/2 Water Absorption <0.01% Maximum Operation Temperature 1450 ºC Transport Package Boxes+Pallets Specification 10x10x2mm Trademark Chemshun Origin China HS Code 69091200 Production Capacity 5000 Tons/Year

Product Description

Chemshun Custom-Made 92% Al2O3 Alumina Ceramic Tile with Size 10X10X2mm

>>> Chemshun Ceramic mosaic tile series :

   - hexagonal ,square, rectangle tile with dimples
   - ceramic block with interlock
   - ceramic cylinder
   - irregular custom ceramics
   - ceramic tile mats

 >>> Alumina ceramic mosaic tile sizes :

Product	Length(mm)	Width(mm)	Thickness including Dimple(mm)
Ceramic Tile with 5dimles	20±0.3	20±0.3	5/6/7/8/9/10
Ceramic Tile with 13dimples	20±0.3	20±0.3	5/6/7/8/9/10
Ceramic Tile with 18dimples	20±0.3	30±0.5	5/6/7/8/9/10
Ceramic Tile with 13dimple	25±0.4	25±0.4	5/6/7/8/9/10
Hex.Tile	12		3/6/10/11/12/20/24/25
Hex Tile	19		5~25
Square Tile	20	20	2~10
Square Tile	17.5	17.5	2~10


>>> Product Characters :

--  High hardness with Moh's hardness 9 grade
--  High abrasion and chemical resistance
--  Special dumps designed for more wear resistance
--  Light weight with various sizes

>>> Chemshun Advantages:

--- Tailor made engineered ceramics available
--- Accept OEM & ODM wear engineered ceramics and project
--- Provide professional industrial wear consult and solution
--- Accept small and big quantity order
--- Delivery fast

>>> Technical data:

S.No.	Attributes	Unit	CHEMSHUN 92 I	CHEMSHUN92 II
1	Alumina Content	%	92	92
2	Density	g/cc	≥3.60	≥3.60
3	Color	-	White	White
4	Water Absorption	%	<0.01	<0.01
5	Flexural Strength	Mpa	270	300
6	Moh's Density	Grade	9	9
7	Rock Well Hardness	HRA	80	85
8	Vickers Hardness(HV5)	Kg/mm2	1000	1150
9	Fracture Toughness (Min)	MPa.m1/2	3-4	3-4
10	Compressive strength	Mpa	850	850
11	Thermal Expansion Coefficient (25-1000ºC)	1x10-6/ºC	8.0	7.6
12	Maximum operation temperature	ºC	1450	1450
