• Model NO.：EBW
• Working Style：High-speed universal
• Disc Diameter：230mm
• Variable Speed：With Variable Speed
• Usage：Industrial
• Product Type：Paint
• Transport Package：Plywooden
• Origin：Shanghai
• HS Code：8479820090
• Production Capacity：200-2000L

Basic Info.

Model NO. EBW Working Style High-speed universal Disc Diameter 230mm Variable Speed With Variable Speed Usage Industrial Product Type Paint Transport Package Plywooden Origin Shanghai HS Code 8479820090 Production Capacity 200-2000L

Product Description

Paint Equipment
1)Introduction Paint Equipment:

Paint Equipment/grinding machine is suitable for industrialized continuous production. The machine applies to materials with various viscosity, can get ideal particle size in shorter time, more efficiency.

Paint Equipment/ grinding machine is one of the highly sophisticated products among the high efficiency milling equipment.

Paint Equipment/ grinding machine is especially famous in the field of process which is high viscosity, high solid content and high refining requirement. It is suitable for product, like pigment, paste, paint, coating, Ink, Agrochemical Concentrate, etc.

2)Features of Paint grinding machine:

--Paint grinding machine is the kind of wet milling machine which is closed continuous production.
--Transportation pump: Diaphragm Pump
--Cylindric chamber with pin or disc spread on the shaft.
--German Burgamann mechanical seal, it can bear more than 10kgs pressure
--Unique discharging structure, solve the traditional problems, such as discharge slowly, stuck the grinding media, leak media...So on
--Grinding chamber adopts special material, the hardness can reach HRC62, ensure that the hardness of the inner tank will be equal before be thoroughly grinded.
--Two kind of cooking system, efficiently down the temperature
With features of solvent-proof, zero pollution and high wearing resistance.

3)Specifications Paint grinding machine

Model	Chamber Volume (ml)	Main Power(kw)	Rotation Speed      (rpm)	Capacity (L/h)	Dimension(mm)	Weight (kgs)
EBW-5	5	7.5	1440	200	1300*1050*450	650
EBW-15	15	18.5	1440	500	1600*1450*650	1200
EBW-20	20	22	1260	800	1600*1450*650	1350
EBW-30	30	37	1260	1200	1650*1550*750	1700
EBW-40	40	45	980	1500	1750*1650*850	2100
EBW-50	50	55	980	2000	1900*1850*850	2300
EBW-100	100	110	860	3000	2300*2150*950	3800
