Bead Mill for Pigment Production High Efficiency Sand Mill

Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.
  • Type：Mill
  • Power Source：Electricity
  • Object：Turbo
  • Application：Chemical
  • Disc(Wheel) Type：Grinding Turbo
  • Material：Zirconia, Stainless Steel

Base Info

  • Working Style：High-speed universal
  • Variable Speed：With Variable Speed
  • Function：Wet Grinding, Milling
  • Grinding Medium：Zirconia Beads
  • Applicable Industry：Coating, Paint, Ink, Pigment, Latex
  • Materials：Stainless Steel or Pure Zirconia
  • Usage：Industrial
  • Product Type：Paint
  • Transport Package：Wooden Case
  • Specification：ENW-5L----ENW-100L
  • Trademark：ELE
  • Origin：Shanghai, China
  • HS Code：8479820090
  • Production Capacity：200-2000L

Description

Basic Info.

Working Style High-speed universal Variable Speed With Variable Speed Function Wet Grinding/ Milling Grinding Medium Zirconia Beads Applicable Industry Coating, Paint, Ink, Pigment, Latex Materials Stainless Steel or Pure Zirconia Usage Industrial Product Type Paint Transport Package Wooden Case Specification ENW-5L----ENW-100L Trademark ELE Origin Shanghai, China HS Code 8479820090 Production Capacity 200-2000L

Product Description

Horizontal Bead Mill (EDW)
Applications:
Middle, Low, High viscosity raw material, suitable for super fineness required Paints and printing inks, high quality car paint, pigments and dyes, ...A high abrasion nanoscale bead mill.


Features:
1. High abrasive resistance: Materials (zirconia, tungsten carbide, hard alloy etc. ) guarantee working life.
2. Dynamic fence booms: Discharge solve problems of slow discharge and grinding medium getting stuck.
3. German BURGMANN double mechanical end face seal, which can bear more than 10bar pressure.

4. Corrugated cooling system increase cooling area and improve cooling efficiency.

5. Grinding beads small to 0.2mm guarantee superfine grinding/milling.

6. Meet demands of continuous production&different viscosity& fineness.

7. Inner & outer double pins improve high wet grinding/milling efficiency.

8. Ex-proof (optional) & fault alarming.
ModelChamber
Volume
(ml)		Main Power
(kw)		Rotation Speed
  (rpm)		Capacity
(L/h)		Dimension
L*W*H
(mm)		Weight
(kg)
EDW-5         5        7.5            1440    2001300*1050*450    650
EDW-15        15      18.5            1440    5001600*1450*650  1200
EDW-20        20        22            1260    8001600*1450*650  1350
EDW-30        30        37            1260   12001650*1550*750  1700
EDW-40        40        45              980   15001750*1650*850  2100
EDW-50        50        55              980   20001900*1850*850  2300
EDW-100      100       110              860   30002300*2150*950  3800
