• Model NO.：PS PASTE
• Application：Grind Polish
• Weight：10g 20g 50g
• Base：Water, Oil
• Transport Package：Carton
• Specification：10g, 50g
• Trademark：SIGNI
• Origin：China
• HS Code：6804221000
• Production Capacity：500000pieces,Year

Basic Info.

Model NO. PS PASTE Application Grind Polish Weight 10g 20g 50g Base Water, Oil Transport Package Carton Specification 10g, 50g Trademark SIGNI Origin China HS Code 6804221000 Production Capacity 500000pieces/Year

Product Description

With top-quality synthetic diamond micro-powder as raw material, the paste features even distribution of micro-powder and even color, without any bubble or agglomeration. The products are divided into water soluble and oil soluble based on nature of cosolvent.

Water soluble grinding paste: Low viscosity; high processing efficiency; slightly corrosive to metals; workable in hostile grinding environment; suitable for processing hard and crisp materials such as glass, ceramics and gemstone.



SIGNI diamond slurry is developed under the advantage of the superior diamond powders produced by ourself manufacturing including PCD, DND and MD series suit for most different applications. It is comprised of diamond powder, dispersant and liquid mediums water or oil. It possesses good dispersibility, uniformly particle size distribution, complete range of specifications and stable performance, widely used for the hard materials lapping and polishing.
Features:

Polycrystalline Diamond Slurry (PCD SLURRY)
Formed by explosive process
High precision finish with good stock removal rate and without scratch
Excellent surface finish on very hard materials such as: Ceramic, glass and hard alloy.
Black in color

Monocrystalline Diamond Slurry (MD SLURRY)
Produced under high pressure and temperature
Multifaceted sphere-cuboid shape for strength and efficiency
Tough Monocrystalline structure with minimal friability
General purpose applications
Gray in color

Nano Diamond Slurry (ND SLURRY)
Made from the detonation of high power explosives and dispersed uniformly in the water
High stability on dispersion
Widely used for ultra precision polishing.
Gray or black in color

Polycrystalline Diamond Slurry
High stock removal rate without scratches, used for the lapping and polishing of sapphire, optic lens, hard glasses, crystals, ceramics, magnetic heads, hard disk and CMOS chip etc. Size (μm) Oil based Water based Size (μm) Oil based Water based
1/20 PC-N50-O PC-N50-W 1 PC-1-O PC-1-W
1/10 PC-N100-O PC-N100-W 2 PC-2-O PC-2-W
1/5 PC-N200-O PC-N200-W 3 PC-3-O PC-3-W
1/4 PC-N250-O PC-N250-W 4 PC-4-O PC-4-W
1/2 PC-N500-O PC-N500-W 6 PC-6-O PC-6-W

Monocrystalline Diamond Slurry
High stock removal rate and low cost, used for the hard materials lapping and polishing. Size (μm) Oil based Water based Size (μm) Oil based Water based
1/20 MD-N50-O MD-N50-W 1 MD-1-O MD-1-W
1/10 MD-N100-O MD-N100-W 2 MD-2-O MD-2-W
1/6 MD-N160-O MD-N160-W 3 MD-3-O MD-3-W
1/4 MD-N250-O MD-N250-W 4 MD-4-O MD-4-W
1/2 MD-N500-O MD-N500-W 6 MD-6-O MD-6-W

Nano Diamond Slurry
Stable dispersibility and superior surface finishing result without scratches, used for the hard materials polishing.
Size (μm) Oil based Water based Size (μm) Oil based Water based
1/30 DND-30-O DND-30-W 1/6 DND-160-O DND-160-W
1/20 DND-50-O DND-50-W 1/5 DND-200-O DND-200-W
1/10 DND-100-O DND-100-W 1/4 DND-250-O DND-250-W

Notes:
Before use, shake bottle of slurry well to ensure that all the grits are evenly suspended.

Packaging:
500ml/bottle

Storage:
Keep temperature above 0° C (32 ° F)
Frozen can result in irreversible product degradation
