220V Concrete Surface Grinding Machine Single Phase Concrete Floor Grinder

Hunan Honway Machinery Equipment Co., Ltd.
  • Type：Disc Grinder
  • Power Source：Electricity
  • Object：Concrete,Marble,Terrazzo,Epoxy
  • Application：Construction
  • Disc(Wheel) Type：Grinding Disc
  • Material：Metal

Base Info

  • Working Style：High-speed universal
  • Disc Diameter：200mm
  • Variable Speed：With Variable Speed
  • Power：4kw
  • Working Width：500mm
  • Weight：191kg
  • Motor Speed：300-1800rpm
  • Current：16A
  • Name：Concrete Floor Surface Grinder
  • Transport Package：Pallet
  • Specification：970*500*800 mm
  • Trademark：HONWAY
  • Origin：China
  • Production Capacity：100 Set,Month

Description

ModelHW-G4AHW-G4BPower220V, 4KW380V,4KWHertzs50/60HZ50/60HZInverter5.5KW5.5KWCurrent12.8A8.8APlate Speed300-1600rpm300-1600rpmWork Area500mm500mmDisc Diameter200mm*3200mm*3Extra Weight20KG20KGWeight191KG191KGL*W*H970*500*800mm970*500*800mm220V Concrete Surface Grinding Machine Single Phase Concrete Floor Grinder
