• Model NO.：EDW
• Working Style：High-speed universal
• Disc Diameter：100mm
• Variable Speed：With Variable Speed
• Lead Time：30-45days
• Usage：Industrial
• Product Type：Paint
• Transport Package：Wooden Case
• Specification：EDW-5----EDW-100
• Trademark：ELE
• Origin：Shanghai, China
• HS Code：879820090
• Production Capacity：300per Month

Basic Info.

Model NO. EDW Working Style High-speed universal Disc Diameter 100mm Variable Speed With Variable Speed Lead Time 30-45days Usage Industrial Product Type Paint Transport Package Wooden Case Specification EDW-5----EDW-100 Trademark ELE Origin Shanghai, China HS Code 879820090 Production Capacity 300per Month

Product Description

Ink Horizontal Pin Mill (EDW)
Features:

1. High abrasive resistance materials: (zirconia, tungsten carbide, hard alloy etc. ) guarantee working life.

2. Dynamic fence-type discharge solve problems of slow discharge and grinding medium stucking.

3. German BURGMANN double mechanical seal can bear more than 10bar pressure.

4. Grinding beads small to 0.2mm guarantee superfine grinding/milling.

5. Meet demands of mass production and differentviscosity.

6. Inner & outer double pins improve high wet grinding/milling efficiency.

7. Explosion-proof system (optional) & fault alarming.

Specifications:

Model	Chamber Volume (ml)	Main Power(kw)	Rotation Speed      (rpm)	Capacity (L/h)	Dimension(mm)	Weight (kgs)
EDW-5	5	7.5	1440	200	1300*1050*450	650
EDW-15	15	18.5	1440	500	1600*1450*650	1200
EDW-20	20	22	1260	800	1600*1450*650	1350
EDW-30	30	37	1260	1200	1650*1550*750	1700
EDW-40	40	45	980	1500	1750*1650*850	2100
EDW-50	50	55	980	2000	1900*1850*850	2300
EDW-100	100	110	860	3000	2300*2150*950	3800
