• Fastening Type：Quick Change
• Color：Gray
• Industrial Cleaning Cloth Type：Sanding Sponge
• Transport Package：Carton
• Origin：Shanghai

Basic Info.

Fastening Type Quick Change Color Gray Industrial Cleaning Cloth Type Sanding Sponge Transport Package Carton Origin Shanghai

Product Description

SIGNI diamond slurry is developed under the advantage of the superior diamond powders produced by ourself manufacturing including PCD, DND and MD series suit for most different applications. It is comprised of diamond powder, dispersant and liquid mediums water or oil. It possesses good dispersibility, uniformly particle size distribution, complete range of specifications and stable performance, widely used for the hard materials lapping and polishing.Features: Polycrystalline Diamond Slurry (PCD SLURRY)Formed by explosive processHigh precision finish with good stock removal rate and without scratchExcellent surface finish on very hard materials such as: ceramic, glass and hard alloy.Black in color Monocrystalline Diamond Slurry (MD SLURRY)Produced under high pressure and temperatureMultifaceted sphere-cuboid shape for strength and efficiencyTough Monocrystalline structure with minimal friabilityGeneral purpose applicationsGray in color Nano Diamond Slurry (ND SLURRY)Made from the detonation of high power explosives and dispersed uniformly in the waterHigh stability on dispersionWidely used for ultra precision polishing.Gray or black in color
Polycrystalline Diamond Slurry
High stock removal rate without scratches, used for the lapping and polishing of sapphire, optic lens, hard glasses, crystals, ceramics, magnetic heads, hard disk and CMOS chip etc.

Size (μm)	Oil based	Water based	Size (μm)	Oil based	Water based
1/20	PC-N50-O	PC-N50-W	1	PC-1-O	PC-1-W
1/10	PC-N100-O	PC-N100-W	2	PC-2-O	PC-2-W
1/5	PC-N200-O	PC-N200-W	3	PC-3-O	PC-3-W
1/4	PC-N250-O	PC-N250-W	4	PC-4-O	PC-4-W
1/2	PC-N500-O	PC-N500-W	6	PC-6-O	PC-6-W

Monocrystalline Diamond Slurry
High stock removal rate and low cost, used for the hard materials lapping and polishing.

Size (μm)	Oil based	Water based	Size (μm)	Oil based	Water based
1/20	MD-N50-O	MD-N50-W	1	MD-1-O	MD-1-W
1/10	MD-N100-O	MD-N100-W	2	MD-2-O	MD-2-W
1/6	MD-N160-O	MD-N160-W	3	MD-3-O	MD-3-W
1/4	MD-N250-O	MD-N250-W	4	MD-4-O	MD-4-W
1/2	MD-N500-O	MD-N500-W	6	MD-6-O	MD-6-W

 Nano Diamond SlurryStable dispersibility and superior surface finishing result without scratches, used for the hard materials polishing.

Size (μm)	Oil based	Water based	Size (μm)	Oil based	Water based
1/30	DND-30-O	DND-30-W	1/6	DND-160-O	DND-160-W
1/20	DND-50-O	DND-50-W	1/5	DND-200-O	DND-200-W
1/10	DND-100-O	DND-100-W	1/4	DND-250-O	DND-250-W

Notes:Before use, shake bottle of slurry well to ensure that all the grits are evenly suspended. Packaging:500ml/bottle Storage:Keep temperature above 0°C (32 °F)Frozen can result in irreversible product degradation Safety Information: see the MSDS.
