• Model NO.：EDF
• Working Style：High-speed universal
• Disc Diameter：100mm
• Variable Speed：Without Variable Speed
• Transport Package：Plywooden Case
• Specification：EDF-400
• Trademark：ELE
• Origin：Shanghai, China
• Production Capacity：0.2-5L

Basic Info.

Model NO. EDF Working Style High-speed universal Disc Diameter 100mm Variable Speed Without Variable Speed Transport Package Plywooden Case Specification EDF-400 Trademark ELE Origin Shanghai, China Production Capacity 0.2-5L

Product Description

EDF-400 lab sand mill is suitable to mix and grind fluidity product which consist of powder-liquid or liquid-liquid. EDF-400 lab sand mill is especially used in pilotscale production, e. G. Lab test or new product research.

Features
Steady performance, digital display;
Low noise, long working life span;
Different working head can be chosen flexibly.

Parameters:

Model	EDF-400
Motor	Carbon  brush  motor
Power	0.4KW
Power  Supply	220V    50Hz
Rotation	0-8000  rpm
Working  head	45  and  60  grinding  disc
Capacity	0.2-5L
Height  adjustment	Manual  lifting
Material	Contact  parts  SUS304/  SUS316L
Falsework	Stainless  steel,   carbon  steel
Speed  control	Stepless  speed  control  with  digital  display
Dimension	45*50*80cm
Weight	23kg
