Woodworking Tools, Diamond and CBN Wheels, Saw and Knife Grinding
Taizhou Sumeng Grinding Wheel Co., Ltd.- Material:Diamond
- Abrasive:Superabrasive
- Shapes:Edge Shape
- Types:Surface Grinding Wheel
- Grain Size:180#
- Cylindricity:<1
Base Info
- Model NO.:TYPE 1A1, 2A2T, 3A1, 4A2
- Circular Degree:<1
- Technics:Sinter
- Working Style:Tool Grinding
- Cold Saw Grinding, Tct Tipped Saw Grindi:Profile Grinding, Carbide Grinding, End Mill Grin
- Glass Cutting, Composite Cutting:Tool Grinding, Ceramic Grinding, PCB, PCBN, Grindi
- Insert Grinding, Thread Grinding:Surface Grinding, Centerless Grinding, Flute Grind
- Centreless Grinding Cut-off Grinding:Peel Grinding Flute Grinding Clearance and Face Su
- Profile Grinding:Roughing Cutter Teeth Grinding
- Gashing: 1V1 / 12V9 etc. 20-30 M/S:End , Face , Od: 11V9 ,12V9 etc.
- External Cylindrical Grinding Machines:Shape 1A1 Shape 6A1 Shape 9A1
- for Wimmer Machine:Cut-off Grinding of Tungsten Carbide Blanks
- Transport Package:BY CARTON
- Specification:EN 12413
- Trademark:BONDFLEX, SAILI, SUMENG
- Origin:JIANGSU CHINA
- HS Code:68042210
- Production Capacity:25000 PIECES each day
Description
Basic Info.
Model NO. TYPE 1A1, 2A2T, 3A1, 4A2 Circular Degree <1 Technics Sinter Working Style Tool Grinding Cold Saw Grinding, Tct Tipped Saw Grindi Profile Grinding, Carbide Grinding, End Mill Grin Glass Cutting, Composite Cutting Tool Grinding, Ceramic Grinding, PCB, PCBN, Grindi Insert Grinding, Thread Grinding Surface Grinding, Centerless Grinding, Flute Grind Centreless Grinding Cut-off Grinding Peel Grinding Flute Grinding Clearance and Face Su Profile Grinding Roughing Cutter Teeth Grinding Gashing: 1V1 / 12V9 etc. 20-30 M/S End / Face / Od: 11V9 /12V9 etc. External Cylindrical Grinding Machines Shape 1A1 Shape 6A1 Shape 9A1 for Wimmer Machine Cut-off Grinding of Tungsten Carbide Blanks Transport Package BY CARTON Specification EN 12413 Trademark BONDFLEX, SAILI, SUMENG Origin JIANGSU CHINA HS Code 68042210 Production Capacity 25000 PIECES each dayProduct Description
Sumeng abrasives is one of the leading abrasives manufacturer with ISO9001: 2000 certificate and German MPA/EN12413 certificate in China. We specialise in the production of the following grinding wheel, cutting wheel, diamond/Boazon wheel etc abrasive products.Face Grind Wright
FACE GRINDING WHEELS FOR WRIGHT EQUIPMENT
D4A2 6 x 1/4 x 1-1/4 D 150 R 100 B 1/16 W=3/16
B12V9 6 x 5/16 x 1-1/4 CBN 120 R 100 B 1/8 30°
D4A2SP 6 x 1/2 x 1-1/4 D 220 R 100 B 1/16 W=1/8
B12V9 6 x 1/2 x 1-1/4 CBN 180 R 100 B 1/16 20°
Top Grind Wright
TOP GRINDING WHEELS FOR WRIGHT EQUIPMENT
D1A2 4-1/2 x 5/16 x 1-1/4 D 120 R 75 B 1/8 W=3/16
B12V9 4-1/2 x 5/16 x 1-1/4 CBN 120 R 100 B 1/8 30°
TOP AND STROBE GRINDING WHEELS FOR WRIGHT EQUIPMENT
D6A2 6 x. 662 x 1-1/4 D 180/400 R 100 B 1/4 W=1/4
B4A1P 5 x 9/16 x 1-1/4 CBN 120 R 75 B 3/16 U=5/32
Side Grind Wright
SIDE GRINDING WHEELS FOR WRIGHT EQUIPMENT
D1A1 4 x 5/32 x 1-1/4 D 120 R 75 B 3/16
B1V1 4 x 1/8 x 1 CBN 120 R 50 B 1/8 V=18°
