• Model NO.：6A2, 6A9, 11V9, 1A1R, 1A1, 4A2, 14A1, 14F1
• Circular Degree：<1
• Technics：Sinter
• Working Style：Tool Grinding
• Resin Bond Diamond Wheel：Grind Tungsten Carbide Tipped Tools
• Resin Bond CBN Wheel：Grind The Circular Saws and Band Saws
• CDX Wheel：The Combination of Carbide and Hardened Tool Steel
• Profile Grinding, Grooving：Cold Saw Grinding, Tct Tipped Saw Grinding
• Insert Grinding, Thread Grinding：Surface Grinding, Centerless Grinding, Flute Grind
• Superabrasive Grinding Wheel：Diamond Wheel, CBN Wheels and CDX Wheels
• Transport Package：By Carton
• Specification：EN 12413
• Trademark：SUMENG, BONDFLEX, SAILI
• Origin：Jiangsu China
• HS Code：68042210
• Production Capacity：25000 pieces each day

Basic Info.

Model NO. 6A2, 6A9, 11V9, 1A1R, 1A1, 4A2, 14A1, 14F1 Circular Degree <1 Technics Sinter Working Style Tool Grinding Resin Bond Diamond Wheel Grind Tungsten Carbide Tipped Tools Resin Bond CBN Wheel Grind The Circular Saws and Band Saws CDX Wheel The Combination of Carbide and Hardened Tool Steel Profile Grinding, Grooving Cold Saw Grinding, Tct Tipped Saw Grinding Insert Grinding, Thread Grinding Surface Grinding, Centerless Grinding, Flute Grind Superabrasive Grinding Wheel Diamond Wheel, CBN Wheels and CDX Wheels Transport Package By Carton Specification EN 12413 Trademark SUMENG, BONDFLEX, SAILI Origin Jiangsu China HS Code 68042210 Production Capacity 25000 pieces each day

Product Description

We specialise in the research, develpomeng and production of resinoid, vitrified and electroplated diamond & CBN wheels. These products are used in the fields of tools, mould & die, bearing, Compressor, Automobile, Aerospace, Ceramic and Magnetic materials and IT.

Diamond Wheels, CBN wheels, CBN Flywheel Grinding wheels

Face Grind Manual
FACE GRINDING WHEELS FOR MANUAL EQUIPMENT FOLEY, BELL, ACME, AUTOOL, NIELSON etc.

D4A2 6 x 3/8 x 1-1/4 D 180 R 75 B 1/16 W=3/16

B4A2 4 x 3/8 x 1/2 CBN 100 R 50 B 1/16 W=3/16

FACE GRINDING WHEELS FOR MANUAL EQUIPMENT

B12A2 6 x 9/16 x 1-1/4 CBN 100 R 75 B 1/16 W=3/16

D4A2 6 x 1/4 x 1-1/4 D 120 R 100 B 1/16 W=1/4

FACE GRINDING WHEELS FOR MANUAL EQUIPMENT JOCKEY, ARSAW, ANDRUS

D12A2 4-1/2 x 7/8 x 5/8sq D 120 R 50 B 1/4 W=1/2

B11A2 3 x 1/2 x 7/8 CBN 100 R 75 B 1/4 W=1/4

FACE GRINDING WHEELS FOR MANUAL EQUIPMENT
4A2 FOR FACE GRINDING PIRANHA TYPE BLADES
12V2 4V2 FOR FACE GRINDING ON MANUAL EQUIPMENT

Top Grind Manual
TOP GRINDING WHEELS FOR MANUAL EQUIPMENT FOLEY, BELL, ACME, SYSTIMATIC etc.

D12A2 6 x 1 x 1-1/4 D 220 R 75 B 1/8 W=3/16

B11V9 5 x 1-3/4 x 1-1/4 CBN 120 R 100 B 1/8

Side Grind Manual
SIDE GRINDING WHEELS FOR MANUAL EQUIPMENT FOLEY, BELL, IMW etc.

D1A1 4 x 5/32 x 1-1/4 D 120 R 75 B 3/16

B1V1 4 x 1/8 x 1 CBN 120 R 50 B 1/8 V=18°

Face Grind Akemat & UT. MA
FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT

D4A2 150mm x 3/8 x 32mm D 240 R 125 B 1/16 W=1/8

B12V9 200mm x 1/2 x 32mm CBN 220 R 100 B 1/16 S=20°

FACE GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT

D4V2 6 x 13/32 x 32mm D 320 R 100 B 3/32 W=1/8

B4V2 200mm x 13mm x 32mm CBN 180 R 100 B 2mm W=4mm

Top Grind Akemat & UT. MA
TOP GRINDING WHEELS FOR AKEMAT AND UT. MA EQUIPMENT

D14B1 125mm x 8mm x 32mm D 180/400 R 100 B 1/4 U=5mm

D3M1 125mm x 8mm x 32mm D 220/600 R 125/100 B 3/8 U=4mm
