High Viscosity Conice Ink Horizontal Beads Mill (EZW)
Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.- Type：Mill
- Usage：Industrial
- Product Type：Paint
- Transport Package：Wooden Case
- Specification：EZW-5----EZW-100
- Trademark：ELE
Base Info
- Model NO.：EZW
- Origin：Shanghai, China
- HS Code：879820090
- Production Capacity：30-2500L
Description
Basic Info.
Model NO. EZW Origin Shanghai, China HS Code 879820090 Production Capacity 30-2500LProduct Description
Ink horizontal beads mill (EZW)Features:
1, high abrasive resistance materials (zirconia, tungsten carbide, hard alloy etc. ) guarantee working life span
2, dynamic fence booms discharge solve problems of slow discharge and grinding medium getting stuck
3, German BURGMANN double end-face mechanical seal can bear more than 10bar pressure
4, screw structure inside cooling jacket increase cooling area and improve cooling efficiency
5, grinding beads small to 0.2mm guarantee superfine grinding/milling
5, meet demands of continuous production
6, especially suitable for high viscosity, high solid-content, superfine grinding/milling
7, inner & outer double pins improve high wet grinding/milling efficiency
8, ex-proof (optional)
9, precise control system & fault alarming
10, kinds of feeding pumps to different processing requirements (e. G. Pneumatic diaphragm pump)
11, low power consumption
Specifications:
| Model | Chamber Volume (ml) | Power (kw) | Speed (rpm) | Capacity (L/H) | Dimension L*W*H (mm) | Weight (kg) |
| EZW-5 | 5 | 7.5 | 1440 | 200 | 1300*1050*450 | 650 |
| EZW-15 | 15 | 18.5 | 1440 | 500 | 1600*1450*650 | 1200 |
| EZW-20 | 20 | 22 | 1260 | 800 | 1600*1450*650 | 1350 |
| EZW-30 | 30 | 37 | 1260 | 1200 | 1650*1550*750 | 1700 |
| EZW-40 | 40 | 45 | 980 | 1500 | 1750*1650*850 | 2100 |
| EZW-50 | 50 | 55 | 980 | 2000 | 1900*1850*850 | 2300 |
| EZW-100 | 100 | 110 | 860 | 3000 | 2300*2150*950 | 380 |
