• Model NO.：FSG-800
• Working Style：Shaking
• Disc Diameter：150mm
• Variable Speed：With Variable Speed
• Table Size(mm)：810X1600,2200,3000,4000
• Max. Ground Area：810X1600,2200,3000,4000
• Max.Ground Height：670(Optional 830,1000)
• Intermittent Feed Rate：1-30 mm,T
• Speed of Table Longitudinal Move：5-25m,Min
• Transport Package：Wooden Package
• Specification：CE
• Trademark：GNG MACHINE
• Origin：China Weihai
• HS Code：8460219000
• Production Capacity：100sets,Month

SG  SGA plc cnc column moving surface grinder  Item/ModelUnitSG60220SDSG60220CNCtable size(WxL)mm610X2200max. grinding(WxL)mm610X2200max. distance between spindle center line and worktable surfacemm820/1050(925)magnetic chuck size (optional equipment)mm600x1000x2speed of table longitudinal movementm/min5-25wheel head cross movingauto feedmm/t1-30rapid speedm/min0.05-2hand wheel feedmm/div0.005wheel head vertical movingauto feedmm/t0.005-0.05rapid speedmm/min0.05-2feed of handwheelmm/div0.005wheelspeedrpm960(1450)size(ODxWxID)mm500x75x305(450x75x203)motor of spindlekw18.5max. loading capacity of worktable with chuckkg1690total rated powerkw28.5height of machine:2720/2920(mm)
floor space(LxW):6000x3000(mm)
gross weight:9500kg
