• Model NO.：M618,M818
• Working Style：Shaking
• Disc Diameter：150mm
• Variable Speed：With Variable Speed
• Table Size(mm)：150X450
• Max.Grinding Size Wxl：160X470
• Magnetic Chuck Size(Optional Equipment)：150X400
• Stroke of Table Cross Motion (mm)：185
• Stroke of Table Left and Right Motion：500
• Transport Package：Wooden Package
• Specification：CE
• Trademark：GNG MACHINE
• Origin：China Weihai
• HS Code：8460219000
• Production Capacity：100sets,Month

M SG manual surface grinder   Item/ModelunitM618Amax. width to be groundmm165max. length to be groundmm470max. height to be groundmm350table sizemm155x460permanent magnetic chuck size(optional)mm150x400max.longitudinal travelmm500max.cross travelmm185max.distance from spindle center to table surfacemm450feed of vertical handwheelper rev.mm1per div.mm0.005grinding wheel size(ODxWxID)mm200x13x31.75spindle speedr/min3450(60Hz),2850(50Hz)power of spindle headkwstandard 1.5(build in spindle:1.1KW)max.load capacity (include permanent magnetic chuck)kg97machine weightkg790machine appearance size(LxWxH)mm1330x1090x1680package dimension(LxWxH)mm1153x1373x1920package size(dismantle table(LxWxH)mm1340x1120x1930
