M71 Wheel Head Moving Surface Grinder

Qingdao G & G Machinery Co., Ltd.
  • Type：Disc Grinder
  • Power Source：Electricity
  • Object：Drilling Bit
  • Application：Construction
  • Disc(Wheel) Type：Grinding Disc
  • Material：Metal

Base Info

  • Model NO.：M7140A
  • Working Style：High-speed universal
  • Disc Diameter：230mm
  • Variable Speed：With Variable Speed
  • Table Size(Wxl)：400X1000(mm)
  • Max. Machining Dimension(Wxl)：400X1000mm)
  • Longitudinal Moving Speed of Worktable：5-25m,Min
  • T-Slot Number X W：3X18(mm)
  • Total Power：11kw
  • Transport Package：Wood Case or Carton
  • Specification：CE ISO
  • Trademark：GNG MACHINE
  • Origin：China
  • HS Code：84595900
  • Production Capacity：500 Sets,Month

Description

table size(WxL)mm400x1000max. machining dimension(WxL)mm400x1000max. distance between spindle center line and worktable surfacemm600longitudinal moving speed of worktablem/min5-25T-slot number x Wmm3x18wheel head cross movingcontinuous feed speedm/min0.5-4.5intermittent feed speedmm/t3-30hand wheel feedmm/gra0.02wheel head vertical movingrapid speedmm/min400feed of handwheelmm/gra0.01wheel head motorpowerkw7.5rotation speedrpm1440total powerkw11max. loading capacity of worktable with chuckkg620chuck size (W x L)mm400x1000x1wheel size (ODxWxID)mm350x40x127wheel size (ODxWxID):311x182x223(mm)
machine dimension(LxWxH):320x220x233(cm)
package dimensions(LxWxH):295x220x223(cm)
machine weight:5.01T
