• Model NO.：Diamond
• Shape：Irregular with Sharp Edge
• Transport Package：Box
• Specification：CBN-B5
• Trademark：Besco
• Origin：Kaifeng
• HS Code：4102940245
• Production Capacity：1500000,Cts,Year

Basic Info.

Model NO. Diamond Shape Irregular with Sharp Edge Transport Package Box Specification CBN-B5 Trademark Besco Origin Kaifeng HS Code 4102940245 Production Capacity 1500000/Cts/Year

Product Description

Specifications

1.Black mono-crystal
2. Irregular shape
3.Low strength
4.Good friability and self-sharp ability
5.used for resin-bondedCubic Boron Nitride/CBN
(CBN) is the second hard material only after synthetic diamond, but having higher heat stability and chemical inertia, so it is unique to machine the black metals and their alloy. Based on this point, the usage of CBN becomes the complementary of diamond, the former is used to process the hard and tough materials, the later is for hard and crisp one.

CBN Applications:
CBN Tools with Resin Bond
CBN Tools with Vitrified Bond
CBN tools with Metal Bond
Electroplated CBN Tools
The choice of CBN size
The choice of CBN concentration
The choice of Coolant

Mesh Size Available:
60/80  80/100 100/120 120/140 140/170 170/200 200/230 230/270 270/325 325/400

Features of  CBN-B1:
 CBN-B1 is a kind of black mono-crystal, with irregular shape, low strength, good friability, and self-sharp ability, usually used for resin bond. By using this material, the tools have the advantages of sharpness, good adaptability, but the tool life is a little low.

product display :
