Wheel Head Moving Surface Grinder Center Machine

Qingdao G & G Machinery Co., Ltd.
  • Type：Disc Grinder
  • Power Source：Electricity
  • Object：Milling Cutter
  • Application：Construction
  • Disc(Wheel) Type：Grinding Disc
  • Material：Metal

Base Info

  • Model NO.：M7130A(AL)
  • Working Style：High-speed universal
  • Disc Diameter：230mm
  • Variable Speed：With Variable Speed
  • Table Size(Wxl)：300X1000(Mm)
  • Max. Machining Dimension(Wxl)：300X1000(Mm)
  • Max. Distance Between Spindle Center Lin：575mm
  • Longitudinal Moving Speed of Worktable：5-25 M,Min
  • T-Slot Number X W：3X18 (Mm)
  • Transport Package：Wood Case
  • Specification：CE ISO
  • Trademark：GNG MACHINE
  • Origin：China
  • HS Code：64595900
  • Production Capacity：500 Sets,Month

Description

M71 wheel head moving surface grinder  Item/ModelUnitM7130A(AL)table size(WxL)mm300x1000max. machining dimension(WxL)mm300x1000max. distance between spindle center line and worktable surfacemm575longitudinal moving speed of worktablem/min5-25T-slot number x Wmm3x18wheel head cross movingcontinuous feed speedm/min0.5-4.5intermittent feed speedmm/t3-30hand wheel feedmm/gra wheel head vertical movingrapid speedmm/min400feed of handwheelmm/gra0.005wheel head motorpowerkw5.5rotation speedrpm1440total powerkw8.63max. loading capacity of worktable with chuckkg470chuck size (W x L)mm300x680x1wheel size (ODxWxID)mm350x40x127machine dimension(LxWxH)cm286x154x203package dimensions(LxWxH)cm284x171x213machine weightt3.6M71 wheel head moving surface grinder machine dimension(LxWxH):'286x154x203(cm)
package dimensions(LxWxH):'284x171x213(cm)
machine weight:3.49T
