Wet Grinding Mill (EDW)
Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.- Type:Pin Type
- Power Source:Electricity
- Object:Ziconia Beads
- Application:Chemical
- Disc(Wheel) Type:Pin
- Material:Steel
Base Info
- Model NO.:EDW
- Working Style:Centrifugal
- Disc Diameter:Different
- Variable Speed:With Variable Speed
- Materials:Stainless Steel or Pure Zirconia
- Application Industry:Emulsion Paint, Latex Paint, Water Paint
- Milling Medium:Zirconia Beads, Ceramic Beads
- Usage:Wet Mill
- Product Type:Cosmetic
- Transport Package:Wooden Case
- Specification:EDW-5------EDW-100
- Trademark:ELE
- Origin:Shanghai, China
- HS Code:8479820090
- Production Capacity:200-2000L
Description
Basic Info.
Model NO. EDW Working Style Centrifugal Disc Diameter Different Variable Speed With Variable Speed Materials Stainless Steel or Pure Zirconia Application Industry Emulsion Paint, Latex Paint, Water Paint Milling Medium Zirconia Beads, Ceramic Beads Usage Wet Mill Product Type Cosmetic Transport Package Wooden Case Specification EDW-5------EDW-100 Trademark ELE Origin Shanghai, China HS Code 8479820090 Production Capacity 200-2000LProduct Description
EDW Wet grinding MillFeatures:
1, high abrasive resistance materials (zirconia, tungsten carbide, hard alloy etc. ) guarantee working life span
2, dynamic fence booms discharge solve problems of slow discharge and grinding medium getting stuck
3, German BURGMANN double end-face mechanical seal can bear more than 10bar pressure
4, screw structure inside cooling jacket increase cooling area and improve cooling efficiency
5, grinding beads small to 0.2mm guarantee superfine grinding/milling
5, meet demands of continuous production
6, especially suitable for high viscosity, high solid-content, superfine grinding/milling
7, inner & outer double pins improve high wet grinding/milling efficiency
8, ex-proof (optional)
9, precise control system & fault alarming
10, kinds of feeding pumps to different processing requirements (e. G. Pneumatic diaphragm pump)
11, low power consumption
Parameters:
Model | Chamber volume(L) | power (KW) | Speed(rpm) | Flow(L/H) | Dimension(mm) | Weight(kgs) |
EDW-1.0 | 1 | 4 | 0-3000 | 2-30 | 1200×900×1400 | 260 |
EDW-5 | 5 | 11 | 0-1500 | 30-200 | 1100×850×1600 | 400 |
EDW-10 | 10 | 22 | 0-1200 | 50-300 | 1400×1100×1750 | 600 |
EDW-15 | 15 | 37 | 0-1200 | 100-500 | 1550×1100×1800 | 1200 |
EDW-30 | 30 | 55 | 0-1000 | 200-1000 | 1850×1300×1700 | 2200 |
EDW-50 | 50 | 75 | 0-860 | >1000 | 2200×1500×1800 | 2800 |
EDW-100 | 100 | 110 | 0-750 | >1500 | 3150×1500×2000 | 5500 |
EDW-150 | 150 | 250 | 0-580 | >2000 | 3300×1500×2300 | 8300 |
EDW-400 | 400 | 500 | 0-480 | >3000 | 3300×1500×2600 | 11700 |
