• Model NO.：SGA-40100AH
• Working Style：Shaking
• Disc Diameter：150mm
• Variable Speed：With Variable Speed
• Table Size(mm)：500X1000
• Max.Grinding Size Wxl(mm)：400X1000
• Max.Distance From Table to Spindle Cente：600mm
• Speed of Table Longitudinal Move：5-25m,Min
• Auto Intermittent Feed：1-20mm,T
• Transport Package：Wooden Package
• Specification：CE
• Trademark：GNG MACHINE
• Origin：China Weihai
• HS Code：8460219000
• Production Capacity：100sets,Month

SGA saddle moving surface grinder  Item/ModelUnitSGA-40100AHSGA-40100AHRSGA-40100AHDtable size(WxL)mm406x1020max. longitudinal travelmm1130max. cross travelmm450max. distance from spindle center to tablemm580electro magnetic chuck sizemm400x1000speed of table longitudinal movementm/min7-23table transverse movementauto feedmm/min0.1-8rapid speedmm/min990feed of handwheelmm/div0.02wheelhead vertical movementauto feedmm---(H/AH/AHR model) 0.005/0.01/0.02/0.03/0.04/0.05(only for AHD model)rapid speedmm/min---(H/AH model) / 460 (for AHR model) 240(only for AHD model)feed of handwheelmm/div0.005grinding wheelspeedrpm1450(50Hz),1750(60Hz)eize(ODxWxID)mm350x40x127spindle motorkw5.5hydranlic motorkw2.2cooling pump motorkw0.125elecating motorkw---(Ah model) 0.25(AHR model) 0.5(AHD model servo motor)cross feed motorkw0.04max.loading capacity of table(include chuck)kg600total rated powerkw9height of machinemm1890floor space(LxW)mm4400x2400Gross weightkg4000package dimensions(LxWxH)mm2950x2270x2210

Table size: 500x1000 mm, three models to select: M,R,A.
Please reply us your needing of optional accesories in the inquiry, thank you.
