Column Moving Surface Grinder Sg-60160

Qingdao G & G Machinery Co., Ltd.
  • Type：Bench Grinder
  • Power Source：Electricity
  • Object：Milling Cutter
  • Application：Construction
  • Disc(Wheel) Type：Grinding Disc
  • Material：Steel

Base Info

  • Model NO.：SG-60160
  • Working Style：Shaking
  • Disc Diameter：150mm
  • Variable Speed：With Variable Speed
  • Table Size(mm)：600X1250
  • Max.Grinding Size Wxl(mm)：600X1250
  • Max.Distance From Table to Spindle Cente：600mm
  • Speed of Table Longitudinal Move：5-25m,Min
  • Auto Intermittent Feed：1-20mm,T
  • Transport Package：Wooden Package
  • Specification：CE
  • Trademark：GNG MACHINE
  • Origin：China Weihai
  • HS Code：8460219000
  • Production Capacity：100sets,Month

Description

SG  SGA plc cnc column moving surface grinder  Item/ModelUnitSG60160SDSG60160CNCtable size(WxL)mm610X1600max. grinding(WxL)mm610X1600max. distance between spindle center line and worktable surfacemm820/1050(925)magnetic chuck size (optional equipment)mm600x800x2speed of table longitudinal movementm/min5-25wheel head cross movingauto feedmm/t1-30rapid speedm/min0.05-2hand wheel feedmm/div0.005wheel head vertical movingauto feedmm/t0.005-0.05rapid speedmm/min0.05-2feed of handwheelmm/div0.005wheelspeedrpm960(1450)size(ODxWxID)mm500x75x305(450x75x203)motor of spindlekw18.5max. loading capacity of worktable with chuckkg1230total rated powerkw28.5height of machinemm2720/2920floor space(LxW)mm4700x3000gross weightkg8500
