• Model NO.：ENW-10
• Working Style：Grinding Bead
• Materials：High Chrome Steel or Pure Zirconia
• Lead Time：20-45days
• Application Industry：Paint, Ink, Pigment, Coating
• Grinding Medium：Zirconia Beads
• Usage：Industrial
• Product Type：Paint
• Seal：Double Mechanical Seal
• Bear：NSK
• Transport Package：Wooden Case
• Specification：ENW-5------ENW-100
• Trademark：ELE
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：200-3000L,H

Basic Info.

Model NO. ENW-10 Working Style Grinding Bead Materials High Chrome Steel or Pure Zirconia Lead Time 20-45days Application Industry Paint, Ink, Pigment, Coating Grinding Medium Zirconia Beads Usage Industrial Product Type Paint Seal Double Mechanical Seal Bear NSK Transport Package Wooden Case Specification ENW-5------ENW-100 Trademark ELE Origin Shanghai, China HS Code 8479820090 Production Capacity 200-3000L/H

Product Description

ELE Mechanical & Electrical Equipment Limited
Turbo type Horizontal bead mill for pigment cosmetical
Model: ENW Series
Chamber volume:1/5/10/15/30/50L

Introduction
ENW series are the international top wet grinding machine, the optimization design of its accelerated wheels will pass more powerful
energy to the grinding medium in chamber. Meanwhile grinding medium distribute more uniform and with more narrow fineness distribution.

 Features:

1.  Suitable for continuous or cyclical process, easy to operation.
2.   Mechanical seal with compact structure,good cooling system ensure the mechanical seal can be long time service.
3.  Fine dispersing and grinding material with different viscosity from micron to nanometer.

Technical Data:


Model	Power (KW)	Rotation (RPM)	Cavity Volume (L)	Bead Loading Volume (KG)	Feeding Size (" &1"=3.33cm)	Capacity (L/H)	Cooling Water Pressure (KG/CM2)	Dimension (CM)	Weight (KG)
ENW-5	7.5~11	1500	5	11	1/2	30-200	1.5-2	120×73×83	450
ENW-15	22~30	1150	15	32	1	100-500	1.5-2	120×55×128	780
ENW-30	37~45	960	30	73	1	300-1500	1.5-2	149×93×143	950
