• Model NO.：chemshun ceramic tile
• Firing Temperature：1680
• OEM：Design According Customer′s Drawings
• Transport Package：Cartons Fixed on Pallet
• Specification：150*100*13,25,50mm
• Trademark：CHEMSHUN
• Origin：Jiangxi, China
• HS Code：6909120000
• Production Capacity：5000ton,Year

Basic Info.

Model NO. chemshun ceramic tile Firing Temperature 1680 OEM Design According Customer′s Drawings Transport Package Cartons Fixed on Pallet Specification 150*100*13/25/50mm Trademark CHEMSHUN Origin Jiangxi, China HS Code 6909120000 Production Capacity 5000ton/Year

Product Description

Manufacturer Suppliers of Alumina Ceramic Tiles Color White Rectangular in South Africa


>> Introduction:

   Alumina wear liner is one of the popular industry abrasion resistant materials ,which is with character of wear resistance , cost effective ,high hardness.high temperature resistance chemshun abrasion resistant ceramics series including alumina ceramic tile , ceramic lining pieces and hexagonal tile mat, ceramic cylinder , pulley lagging ceramics etc. These wear resistant ceramic liner is easy to installed with epoxy resin , cement , some mosaic pieces is best abrasion materials for vulcanized in rubber sheet. Ceramic weldable tile liner as typical wear lining introduced as follows :

>> Characteris :
High hardness
Superior abrasion resistance
Corrosion and chemical resistance
Light weight
Can be applied in all kinds industrial abrasion solution field
>> Size available (Length*width*thickness ) :


Alumina ceramic weldable tile popular Sizes  (Length*width*thickness )

100*100*20mm  (4"x4"x3/4")

150*100*13mm  (6"x4"x1/2")

150*100*15mm  (6"x4"x5/8")

150*100*20mm  (6"x4"x3/4")

150*100*25mm  (6"x4"x1")

150*100*50mm  (6"x4"x2")

150*50*25mm   (6"x4"x1")

100*75*25mm   (4"x3"x1")

120*80*20mm

228*114*25mm

114*114*25mm

More sizes and customized size acceptable. Chemshun ceramics afford the relative weldable steel cone and ceramic rod.

>> Application industry:
mining industry
Cement industry
Coal handling industry
Steel industry
Port industry
Power plant

>> Tehcnical data :

1  :Chemical Composition:

Al2O3	SiO2	CaO	MgO	Na2O
92~93%	3~6%	1~1.6%	0.2~0.8%	0.1%

Physical properties:

Specific gravity (g/cc)	>3.60
Apparent porosity (%)	0
Flexural Strength (20ºC, Mpa)	>280
Compressive strength (20ºC, Mpa)	850
Rockwell hardness (HRA)	>80
Vickers hardness (hv)	1050
Moh's hardness (scale)	≥9
Thermal Expansion (20-800ºC, x10-6/ºC)	8
Crystal Size (μm)	1.3~3.0

>> Service:
Any requirment about chemshun Alumina Ceramic Chute Liner , wear resistant  linings , chute liner desinged or maintenance . please feel free contact us and chemshun we'll afford you the most suitable product and best service. web:chemshun.en.made-in-china.com .

>> Export:
Our products have been exported to many countries: Australia, Chile, USA, Russia, UK, Indonesia, etc., good quality have be approved by our clients.
