CNC Column Moving Surface Grinder

Qingdao G & G Machinery Co., Ltd.
  • Type：Sga PLC CNC Column Moving Surface Grinder
  • Power Source：Electricity
  • Object：Milling Cutter
  • Application：Construction
  • Disc(Wheel) Type：Grinding Disc
  • Material：Metal

Base Info

  • Model NO.：SG60330SD
  • Working Style：High-speed universal
  • Disc Diameter：230mm
  • Variable Speed：With Variable Speed
  • Table Size(Wxl)：610X3000(Mm)
  • Max. Grinding(Wxl)：610X3000(Mm)
  • Magnetic Chuck Size (Optional Equipment)：600X1000X3(Mm)
  • Speed of Table Longitudinal Movement：5-25m,Min
  • Transport Package：Wood Case
  • Specification：CE
  • Trademark：GNG MACHINE
  • Origin：China
  • HS Code：84595900
  • Production Capacity：100sets,Month

Description

SG  SGA plc cnc column moving surface grinder  Item/ModelUnitSG60330SDSG60300CNCtable size(WxL)mm610X3000max. grinding(WxL)mm610X3000max. distance between spindle center line and worktable surfacemm820/1050(925)magnetic chuck size (optional equipment)mm600x1000x3speed of table longitudinal movementm/min5-25wheel head cross movingauto feedmm/t1-30rapid speedm/min0.05-2hand wheel feedmm/div0.005wheel head vertical movingauto feedmm/t0.005-0.05rapid speedmm/min0.05-2feed of handwheelmm/div0.005wheelspeedrpm960(1450)size(ODxWxID)mm500x75x305(450x75x203)motor of spindlekw18.5max. loading capacity of worktable with chuckkg2300total rated powerkw28.5height of machine:2720/2920(mm)
floor space(LxW):8200x3000(mm)
gross weight: 12500 kg
